Features
Next-generation JBL driver technology
The new 2409H High Frequency transducer incorporates an innovative low-mass annular diaphragm that delivers smooth response beyond 40 kHz, with extraordinary output and very low distortion. New 728G 8” high-excursion low frequency driver in the 708i delivers continuously high output with minimal power compression and low frequency response into the 30Hz range.
Patented Image Control Waveguide
The JBL Image Control Waveguide ensures accuracy and neutrality while providing a wide sweet spot with increased sonic detail. By enabling an acoustically seamless transition between the woofer and high-frequency transducer, the waveguide provides a detailed soundstage and accurate imaging across the entire frequency spectrum. Smooth, neutral on- and off-axis frequency response allows the JBL 708i to “hear the same story” regardless of listening position and room.
Specs & Downloads
Item# LSR708I
Description
Dive in
The first in JBL’s new 7 Series line, the 705i and 708i models answer the call for next generation multi-channel monitoring in post rooms, broadcast facilities and trucks. Leveraging patented technologies developed for our flagship M2 Master Reference Monitor, 7 Series Studio Monitors deliver detailed imaging, extended frequency response and remarkable output from compact enclosures. Centrally amplified and tuned, and easily installed, 705i and 708i Studio Monitors are the heart of an elegant, scalable system for broadcast and post facilities working in immersive audio formats.
General Specifications
- Frequency Response
- -1.5 dB @ 45Hz – 23kHz
- Frequency Range
- 35Hz – 36 kHz
- Max SPL
- (80 Hz - 20 kHz) >108 dB SPL / 1m
- Maximum Peak SPL
- (80 Hz - 20 kHz) >114 dB SPL / 1m
- HF Driver
- 2409H
- LF Driver
- 728G
- Dividing Network Transition Frequency
- 1.7 kHz
- Input Types
- Phoenix Terminals accept 12 gauge speaker wire
- Enclosure
- Birch plywood reinforced for mounting
- Mounting
- Top, bottom and rear mounting points. 4-hole mounting pattern
Dimensions
- Height
- 438 mm
- Width
- 248 mm
- Depth
- 292 mm
- Weight
- 11.5 kg
Country of Origin
- China
- -
What's in The Box?
- 1 x 708i Master Reference Monitor
- 1 x Quick Set Up Guide
